Documentation of axi_crossbar release

This document contains technical documentation for the axi_crossbar FPGA module. It is generated from release axi_crossbar-0.0.0 at 2023-02-28 07:21.

Release notes

Changelogs from Truestream follow the keep a changelog format. Version numbers follow the semantic versioning scheme: MAJOR.MINOR.PATCH+HASH.

• MAJOR will be incremented for incompatible API or functionality changes.

• MINOR will be incremented when new functionality is added in a backwards compatible manner.

• PATCH will be incremented for backwards compatible bug fixes.

The HASH field is the Git SHA that the release was made from. It is included in the version number for internal traceability.

Release history and changelog follows below.

3.1.0+73746267 - (28 february 2023)

• Add support for passthrough mode (num_left_ports = 1) that consumes no resources (unless asynchronous operation is enabled).

3.0.0+a4f1024a - (24 march 2021)

Added

• Break out axi_write_crossbar_core with simpler interface. The existing axi_write_crossbar instantiates the new core with no functional changes.

Breaking changes

• Adapt for latest tsfpga.

2.0.0+c995aaf0 - (21 august 2020)

Breaking changes

• Adapt for tsfpga version 4.0.0

1.0.0+84f2ce18 - (25 june 2020)

Initial release.

Design details

See the Module axi_crossbar page for an overview and specification of the axi_crossbar module. Here you will also find a technical description of the different sub-modules.

Requirements

This module has the following dependencies:

• The open-source hdl_modules project version 2.0.0.

Library name

This module’s source files shall be compiled to a VHDL library symbolically named axi_crossbar.
