Documentation of off_chip_fifo release

This document contains technical documentation for the off_chip_fifo FPGA module. It is generated from release off_chip_fifo-0.0.0 at 2023-02-28 07:21.

Release notes

Changelogs from Truestream follow the keep a changelog format. Version numbers follow the semantic versioning scheme: MAJOR.MINOR.PATCH+HASH.

  • MAJOR will be incremented for incompatible API or functionality changes.

  • MINOR will be incremented when new functionality is added in a backwards compatible manner.

  • PATCH will be incremented for backwards compatible bug fixes.

The HASH field is the Git SHA that the release was made from. It is included in the version number for internal traceability.

Release history and changelog follows below.

1.0.0+bbccb3f4 - (28 february 2023)

Initial release.

Design details

See the Module off_chip_fifo page for an overview and specification of the off_chip_fifo module. Here you will also find a technical description of the different sub-modules.

Requirements

This module has the following dependencies:

  • The open-source hdl_modules project version 2.0.0.

  • The Truestream module axi_master version 1.0.0.

  • The Truestream module ring_buffer_manager version 0.0.1.

Library name

This module’s source files shall be compiled to a VHDL library symbolically named off_chip_fifo.
